FAW Jiefang J6P pilot version 500 horsepower 8X4 8.2 meter dump truck
Submit purchase requestBasic Information
- Drive form:
- 8X4
- Wheelbase:
- 2000+4400+1350mm
- Body length:
- 11.195 meters
- Body width:
- 2.55 meters
- Body height:
- 3.4 meters
- Front track:
- 2056/2056mm
- Rear wheelbase:
- 1878/1878mm
- Vehicle weight:
- 15.5 tons
Truck Picture
Truck Configuration
Basic Information
- Drive form
- 8X4
- Wheelbase
- 2000+4400+1350mm
- Body length
- 11.195 meters
- Body width
- 2.55 meters
- Body height
- 3.4 meters
- Front track
- 2056/2056mm
- Rear wheelbase
- 1878/1878mm
- Vehicle weight
- 15.5 tons
- Rated load
- 15.37 tons
- Total mass
- 31 tons
- Tonnage level
- Heavy Truck
- Approach angle
- 24 degrees
- Departure angle
- 23 degrees
- Origin
- Qingdao,Changchun
- Remark
- Optional 5.263 speed ratio.
- Version
- Pilot version
Engine parameters
- engine model
- Xichai CA6DM3-50E68
- Engine brand
- xichai
- Number of cylinders
- 6 cylinder
- Fuel type
- diesel fuel
- Displacement
- 12.52L
- Emission Standards
- National VI
- Maximum horsepower
- 500 HP
- Maximum output power
- 370kW
Gearbox parameters
- Gearbox model
- FAW Jiefang CA12TAX250F
- Gearbox brand
- FAW Jiefang
- Forward gear
- 12 gears
- Number of reverse gears
- 2
- Shifting method
- Manual
Chassis parameters
- Frame size
- 300×80×(8+8+5)mm
- Front axle description
- F9N
- Allowable load on front axle
- 6500/6500kg
- Rear axle description
- ф300 cast steel wheel bridge reduction
- Allowable load on rear axle
- 18000(two-axle group)kg
- Speed ratio
- 5.921
- Number of spring leaves
- 11/13/14
- clutch
- Φ430
- Tire specifications
- 12.00R20 18PR
- Number of tires
- 12
- Fuel tank material
- Aluminum alloy
- Fuel tank capacity
- 600L
- Carton length
- 8.2 meters
- Cargo box width
- 2.35 meters
- Cargo box height
- 1.5 m
- Container form
- Self-unloading
