FAWQD Jiefang Han V heavy truck version 2.0 350 horsepower 8X4 6.5 meter dump truck
Submit purchase requestBasic Information
- Drive form:
- 8X4
- Wheelbase:
- 1900+3200+1350mm
- Body length:
- 9.66 meters
- Body width:
- 2.55 meters
- Body height:
- 3.25 meters
- Front track:
- 2020/2020mm
- Rear wheelbase:
- 1878/1878mm
- Vehicle weight:
- 14.62 tons
Truck Picture
Truck Configuration
Basic Information
- Drive form
- 8X4
- Wheelbase
- 1900+3200+1350mm
- Body length
- 9.66 meters
- Body width
- 2.55 meters
- Body height
- 3.25 meters
- Front track
- 2020/2020mm
- Rear wheelbase
- 1878/1878mm
- Vehicle weight
- 14.62 tons
- Rated load
- 16.25 tons
- Total mass
- 31 tons
- Tonnage level
- Heavy Truck
- Approach angle
- 25 degree
- Departure angle
- 37 degree
- Origin
- Qingdao
- Market segments
- Road transport
Engine parameters
- engine model
- Weichai WP8.350E61
- Engine brand
- Weichai
- Number of cylinders
- 6
- Fuel type
- diesel fuel
- Displacement
- 7.8L
- Emission Standards
- National VI
- Maximum horsepower
- 350 HP
- Maximum output power
- 257kW
- Maximum torque
- 1400N·m
- Maximum torque speed
- 1200-1600rpm
- Rated speed
- 2100rpm
- Engine form
- In-line six-cylinder, water-cooled, four-stroke, high-pressure common rail, supercharged intercooling, EGR
Gearbox parameters
- Gearbox model
- FAW Jiefang CA10TAX130M
- Gearbox brand
- FAW Jiefang
- Forward gear
- 10 gears
- Number of reverse gears
- 2
- Shell material
- Aluminum shell
Chassis parameters
- Frame size
- 280*80*(8+5)mm
- Allowable load on front axle
- 6500/6500kg
- Rear axle description
- 435 upgraded stamping and welding bridge (with differential lock between wheels)
- Allowable load on rear axle
- 18000(two-axle group)kg
- Speed ratio
- 5.143
- Number of spring leaves
- 10/10/10,12/12/10,4/4/5,4/4/10
- Tire specifications
- 10.00R20 18PR,11.00R20 16PR,11.00R20 18PR
- Number of tires
- 12
- Fuel tank capacity
- 300L
- Carton length
- 6.5 meters
- Cargo box width
- 2.35 meters
- Cargo box height
- 1.5 m
- Container form
- Back flip dump type
