SINOTRUK HOWO T7H heavy truck 440 horsepower 8X4 8m dump truck
Submit purchase requestBasic Information
- Drive form:
- 8X4
- Wheelbase:
- 1950+4200+1400mm
- Body length:
- 11.165 meters
- Body width:
- 2.496 meters
- Body height:
- 3.635 meters
- Front track:
- 2041/2041mm
- Rear wheelbase:
- 1830/1830mm
- Vehicle weight:
- 15.4 tons
Truck Picture
Truck Configuration
Basic Information
- Drive form
- 8X4
- Wheelbase
- 1950+4200+1400mm
- Body length
- 11.165 meters
- Body width
- 2.496 meters
- Body height
- 3.635 meters
- Front track
- 2041/2041mm
- Rear wheelbase
- 1830/1830mm
- Vehicle weight
- 15.4 tons
- Rated load
- 15.47 tons
- Total mass
- 31 tons
- Tonnage level
- Heavy Truck
- Approach angle
- 16 degrees
- Departure angle
- 24 degrees
- Origin
- Shandong Jinan
- Market segments
- Mining engineering
- Remark
- Optional 300X (8+8+8) frame and hydraulic retarder
Engine parameters
- engine model
- Sinotruk MC11.44-50
- Engine brand
- SINOTRUK
- Number of cylinders
- 6
- Fuel type
- diesel fuel
- Displacement
- 10.518L
- Emission Standards
- National Five
- Maximum horsepower
- 440 HP
- Maximum output power
- 324kW
- Maximum torque
- 2100N·m
- Maximum torque speed
- 1000-1400rpm
- Rated speed
- 1900rpm
- Engine form
- In-line, water-cooled, four-stroke, supercharged and intercooled
Gearbox parameters
- Gearbox model
- SINOTRUK HW19712C
- Gearbox brand
- SINOTRUK
- Forward gear
- 12 gears
- Number of reverse gears
- 2
Chassis parameters
- Front axle description
- HF9
- Allowable load on front axle
- 6500/7000kg
- Rear axle description
- AC16
- Allowable load on rear axle
- 17500(double axle installed)kg
- Speed ratio
- 5.45
- Suspension type (front/rear)
- Reinforce before and after
- Number of spring leaves
- 11/11/12
- Tire specifications
- 12.00R20
- Number of tires
- 12
- Fuel tank material
- Aluminum alloy
- Fuel tank capacity
- 400L
- Carton length
- 8 meters
- Cargo box width
- 2.35 meters
- Cargo box height
- 1.5 m
- Container form
- Self-unloading
