Dongfeng Liuqi Chenglong H7 heavy truck 520 horsepower 4X2 AMT automatic transmission tractor
Submit purchase requestBasic Information
- Drive form:
- 4X2
- Wheelbase:
- 4000mm
- engine:
- Dongfeng Cummins Z13NS6B520F
- Gearbox:
- Fast F12JZ24A
- Rear axle speed ratio:
- 3.083
- Body length:
- 6.24 meters
- Body width:
- 2.525 meters
- Body height:
- 3.67 meters
Truck Picture
Truck Configuration
Basic Information
- Drive form
- 4X2
- Wheelbase
- 4000mm
- engine
- Dongfeng Cummins Z13NS6B520F
- Gearbox
- Fast F12JZ24A
- Rear axle speed ratio
- 3.083
- Body length
- 6.24 meters
- Body width
- 2.525 meters
- Body height
- 3.67 meters
- Front track
- 2040mm
- Rear wheelbase
- 1860mm
- Vehicle weight
- 6.8 tons
- Total mass
- 17.995 tons
- Total traction mass
- 35 tons
- Maximum speed
- 89km/h
- Market segments
- Express Express
- Origin
- Liuzhou, Guangxi
- Tonnage level
- Heavy Truck
Engine parameters
- engine model
- Dongfeng Cummins Z13NS6B520F
- Engine brand
- Dongfeng Cummins
- Number of cylinders
- 6 cylinder
- Fuel type
- diesel fuel
- Cylinder arrangement
- inline
- Displacement
- 12.5L
- Emission Standards
- National VI
- Maximum horsepower
- 520 HP
- Maximum output power
- 382kW
Gearbox parameters
- Gearbox model
- Fast F12JZ24A
- Shifting method
- AMT automated manual
- Forward gear
- 12 gears
- Number of reverse gears
- 2
Chassis parameters
- Frame size
- 264 (6) single layer mm
- Front axle description
- 153 enhanced (maintenance-free)
- Rear axle description
- FS160 (maintenance-free)
- Allowable load on front axle
- 6505kg
- Allowable load on rear axle
- 11490kg
- Speed ratio
- 3.083
- Number of spring leaves
- 2/-
- clutch
- Φ430
- Steering gear
- Domestic
- Saddle
- 50#
- Tire specifications
- 295/80R22.5 16PR
- Number of tires
- 6
- Fuel tank/gas tank material
- Aluminum alloy
- Fuel tank capacity
- 600+450LL
