XCMG Hanfeng P9 580 HP 6X4 AMT automatic tractor
Submit purchase requestBasic Information
- Drive form:
- 6X4
- Wheelbase:
- 3400+1350mm
- engine:
- Weichai WP13.580E62
- Gearbox:
- Fast 12 gears
- Body length:
- 6.92 meters
- Body width:
- 2.55 meters
- Body height:
- 3.12 meters
- Front track:
- 2020mm
Truck Picture
Truck Configuration
Basic Information
- Drive form
- 6X4
- Wheelbase
- 3400+1350mm
- engine
- Weichai WP13.580E62
- Gearbox
- Fast 12 gears
- Body length
- 6.92 meters
- Body width
- 2.55 meters
- Body height
- 3.12 meters
- Front track
- 2020mm
- Rear wheelbase
- 1860/1860mm
- Vehicle weight
- 8.87 tons
- Total mass
- 25 tons
- Total traction mass
- 40 tons
- Maximum speed
- 90km/h
- Market segments
- Logistics distribution
- Origin
- Xuzhou Jiangsu
- Tonnage level
- Heavy Truck
Engine parameters
- engine model
- Weichai WP13.580E62
- Engine brand
- Weichai
- Number of cylinders
- 6
- Fuel type
- diesel fuel
- Cylinder arrangement
- inline
- Displacement
- 12.54L
- Emission Standards
- National VI
- Maximum horsepower
- 580 HP
- Maximum output power
- 426kW
- Maximum torque
- 2550N·m
- Maximum torque speed
- 950-1400rpm
- Rated speed
- 1900rpm
Gearbox parameters
- Gearbox model
- Fast 12 gears
- Shifting method
- AMT automated manual
- Forward gear
- 12 gears
- Number of reverse gears
- 2
Chassis parameters
- Allowable load on front axle
- 7000kg
- Allowable load on rear axle
- 18000(two-axle group)kg
- Number of spring leaves
- 2/-
- Saddle
- 90#
- Number of tires
- 10
- Tire specifications
- 12R22.5 18PR
