Foton Auman GTL Star Wing Edition 440HP 4X2 Tractor Truck
Submit purchase requestBasic Information
- Drive type:
- 4X2
- Wheelbase:
- 3600mm
- engine:
- Foton Cummins A10NS6B440
- Gearbox:
- Fast 12JSDX240TA
- Rear axle ratio:
- 2.846
- Body length:
- 6.065m
- Body width:
- 2.525 m
- Body height:
- 3.8 m
Truck Picture
Truck Configuration
Basic Information
- Drive type
- 4X2
- Wheelbase
- 3600mm
- engine
- Foton Cummins A10NS6B440
- Gearbox
- Fast 12JSDX240TA
- Rear axle ratio
- 2.846
- Body length
- 6.065m
- Body width
- 2.525 m
- Body height
- 3.8 m
- Front track
- 2020mm
- Rear track
- 1865mm
- Vehicle weight
- 6.65 tons
- Total mass
- 18 tons
- Total traction mass
- 35.22 tons
- Maximum speed
- 89km/h
- Origin
- Beijing Huairou
- Tonnage level
- Heavy Truck
- Remark
- Speed ratio optional 2.733/3.083
- Version
- Star Wing Edition
Engine parameters
- engine model
- Foton Cummins A10NS6B440
- Engine brand
- Foton Cummins
- Number of cylinders
- 6 cylinders
- Fuel type
- diesel fuel
- Cylinder arrangement
- In-line
- Displacement
- 9.92L
- Emission Standards
- National VI
- Maximum horsepower
- 440 hp
- Maximum output power
- 353kW
Gearbox parameters
- Gearbox model
- Fast 12JSDX240TA
- Gearbox brand
- Fast
- Shifting method
- Manual
- Forward gears
- 12 gears
- Reverse gear number
- 2
- Shell Material
- Aluminum Alloy
Chassis parameters
- Permissible load on front axle
- 6500kg
- Permissible load on rear axle
- 11500kg
- Speed ratio
- 2.846
- Number of springs
- 2/3+2
- Suspension type (front/rear)
- Leaf spring suspension
- Number of tires
- 6
- Tire specifications
- 12R22.5 18PR
