SITRAK G7H luxury version 540 horsepower 8X4 9.52m AMT automatic transmission wing opening van truck
Submit purchase requestBasic Information
- type:
- van truck
- Drive form:
- 8X4
- Wheelbase:
- 1950+4600+1400mm
- Box length level:
- 9.5 meters
- engine:
- Sinotruk MC13H.54-61
- Gearbox:
- ZF ZF12TX2620TD
- Rear axle speed ratio:
- 2.85
- Body length:
- 12 meters
Truck Picture
Truck Configuration
Basic Information
- type
- van truck
- Drive form
- 8X4
- Wheelbase
- 1950+4600+1400mm
- Box length level
- 9.5 meters
- engine
- Sinotruk MC13H.54-61
- Gearbox
- ZF ZF12TX2620TD
- Rear axle speed ratio
- 2.85
- Body length
- 12 meters
- Body width
- 2.55 meters
- Body height
- 3.98 meters
- Front track
- 2022/2022mm
- Rear wheelbase
- 1830/1830mm
- Vehicle weight
- 13.35 tons
- Rated load
- 18.52 tons
- Total mass
- 32 tons
- Maximum speed
- 89KM/h
- Origin
- Zhangqiu, Shandong
- Tonnage level
- heavy duty truck
- Approach angle
- 19 degrees
- Departure angle
- 17 degrees
- Remark
- Lightweight frame, Bosch steering gear.
- Front suspension/rear suspension
- 1.492/2.558 meters
Engine parameters
- engine model
- Sinotruk MC13H.54-61
- Engine brand
- SINOTRUK
- Common name of engine
- Sinotruk MC13
- Number of cylinders
- 6 cylinder
- Fuel type
- diesel fuel
- Cylinder arrangement
- inline
- Displacement
- 13.02L
- Emission Standards
- National VI
- Maximum output power
- 400kw
- Maximum horsepower
- 540 HP
- Maximum torque
- 2500N·m
- Maximum torque speed
- 950-1400RPM
- Rated speed
- 1800RPM
- Engine form
- In-line six-cylinder, water-cooled, four-stroke, supercharged and intercooled, high-pressure common rail
Gearbox parameters
- Gearbox model
- ZF ZF12TX2620TD
- Shifting method
- AMT automated manual
- Forward gear
- 12 gears
- Number of reverse gears
- 4
Chassis parameters
- Front axle description
- 5T front axle
- Allowable load on front axle
- 6500/7000KG
- Frame size
- 8/280mm
- Rear axle description
- 12T double rear axle
- Allowable load on rear axle
- 18500(two-axis group)KG
- Speed ratio
- 2.85
- Number of spring leaves
- 3/3/2+-/2+-
- Suspension type (front/rear)
- Front and rear single swing arm air suspension
- Tire specifications
- 12R22.5 18PR
- Number of tires
- 12
- Fuel tank material
- Aluminum alloy
- Fuel tank capacity
- 900L
- Container form
- wingspan
- Carton length
- 9.52 meters
- Cargo box width
- 2.45 meters
- Cargo box height
- 2.6 meters
