FAWQD Jiefang JH6 heavy truck pilot version 320 horsepower 6X2 9.8m box truck
Submit purchase requestBasic Information
- type:
- van truck
- Drive form:
- 6X2
- Wheelbase:
- 1900+5600mm
- Box length level:
- 9.8 meters
- engine:
- Dachai CA6DK1-32E6
- Gearbox:
- FAW Jiefang CA10TAX130M
- Rear axle speed ratio:
- 4.1
- Body length:
- 12 meters
Truck Picture
Truck Configuration
Basic Information
- type
- van truck
- Drive form
- 6X2
- Wheelbase
- 1900+5600mm
- Box length level
- 9.8 meters
- engine
- Dachai CA6DK1-32E6
- Gearbox
- FAW Jiefang CA10TAX130M
- Rear axle speed ratio
- 4.1
- Body length
- 12 meters
- Body width
- 2.55 meters
- Body height
- 3.995 meters
- Front track
- 1938/1938mm
- Rear wheelbase
- 1878mm
- Vehicle weight
- 10.6 tons
- Rated load
- 14.27 tons
- Total mass
- 25 tons
- Maximum speed
- 110km/h
- Origin
- Qingdao
- Tonnage level
- medium card
- Approach angle
- 25 degree
- Departure angle
- 10 degrees
- Market segments
- City delivery
- Front suspension/rear suspension
- 1.41/3.09 meters
- Version
- Pilot version
Engine parameters
- engine model
- Dachai CA6DK1-32E6
- Engine brand
- Dachai
- Common name of engine
- Dachai 6 cylinder
- Number of cylinders
- 6 cylinder
- Fuel type
- diesel fuel
- Cylinder arrangement
- inline
- Displacement
- 7.2L
- Emission Standards
- National VI
- Maximum output power
- 235kw
- Maximum horsepower
- 320 HP
- Maximum torque
- 1300N·m
- Maximum torque speed
- 1200-1700RPM
- Rated speed
- 2300RPM
- Engine form
- High voltage common rail+EGR+DOC+DPF+SCR+ASC
Gearbox parameters
- Gearbox model
- FAW Jiefang CA10TAX130M
- Shifting method
- Manual
- Forward gear
- 10 gears
- Number of reverse gears
- 2
Chassis parameters
- Allowable load on front axle
- 6750/6750KG
- Frame size
- 270×75×7mm
- Rear axle description
- 457 upgrade stamping and welding bridge
- Allowable load on rear axle
- 11500KG
- Speed ratio
- 4.1
- Number of spring leaves
- 3/3+3
- clutch
- Φ430
- Tire specifications
- 11.00R20 18PR
- Number of tires
- 8
- Fuel tank material
- iron
- Container form
- warehouse gate type
- Carton length
- 9.8 meters
- Cargo box width
- 2.4 meters
